Name: 2.9 Inch E ink Flexible Ultra-thin 4 Grayscale E-paper Display 0.3s Partial Refresh
Brand: GOOD DISPLAY
SKU: GDEW029I6F
Price: 11.95 USD
Availability: InStock
Rating: 5 (1 reviews)

Description

		Discover the 2.9'' E Ink Display with Flexibility and 4 Grayscales
		Imagine a display so versatile and power-efficient, it seamlessly integrates into your life. This cutting-edge e-paper module, featuring a flexible substrate, delivers crisp 296x128 resolution with a SPI interface, perfect for displaying images in sharp black and white contrast. What sets this display apart is its remarkable efficiency: it supports both a quick 3-second full refresh and an ultra-fast 0.3-second partial refresh. Once your image is set, it remains vividly displayed indefinitely without any power consumption – a true marvel of technology! This makes it ideal for applications where power efficiency is crucial, whether it's in solar-powered devices or those powered by batteries. Imagine using this display in e-readers that never need recharging, smart home devices with minimal energy demands, or innovative signage solutions that stay on 24/7 without driving up energy costs. Its flexibility allows for creative designs that can conform to various shapes and sizes, offering unmatched versatility in product design.

Our product boasts distinctive features that set it apart from the competition

●  Embrace Innovation with Our Ultra-Thin Flexible E-Paper – Just 0.34mm Thin! Perfect for Curved Designs and Seamless Integration in Any Product.
●  Transform Your Experience: Full Screen Refresh in Just 3 Seconds, Lightning-fast 0.3-Second Partial Refresh for Instant, Fluid Interaction!
●  Unbelievably Low Power Consumption: Powers up only for updates, making it perfect for long-term use in smart tags.
●  Crystal-Clear Visibility: Enjoy glare-free viewing with pure reflective technology, delivering vivid clarity even under direct sunlight.
●  Always Reliable: Dual-state display ensures your content stays intact even without power, ideal for uninterrupted information display.
●  Health-Conscious Innovation: Say goodbye to eye strain with zero blue light emissions, designed for extended reading and sustainable living.

		Technical Details
		Please refer to the product drawings for detailed dimensions

Please refer to the product specifications for more details

PART NUMBER	GDEW029I6FD	CONNECTOR	24 Pin FPC
SIZE	2.9 inch	TYPE	Dot Matrix
IC	UC8151D	MAX GRAYSCALE	4
RESOLUTION	296x128	COLOR	Black, White
OUTLINE SIZE(mm)	79x36.7x0.34	INTERFACE	SPI
ACTIVE SIZE(mm)	66.9x29.06	FULL REFRESH(s)	3
PIXEL PITCH(mm)	0.227x0.226	PARTIAL REFRESH TIME(s)	0.3
OPERATING TEMP.	0℃~50℃	POWER CONSUMPTION OF THE REFRESH(mW)	26.4
STORAGE TEMP.	-25℃~70℃	STANDBY POWER CONSUMPTION (mW)	0.0165

Matching Driver Board
To facilitate the testing and comparison of e-paper, we recommend the following driver boards for you.

a. DESPI-C02 (E-ink Display adapter Board)	b. DESPI-L(C02) (STM32 Demo Kit)	c. DEArduino-L(C02) (Arduino Platform Demo Kit)

d.ESP8266-L(C02) (ESP8266 Demo Kit)	e.ESP32-L(C02) (ESP32 Demo Kit)

Related Information Download Click on the subheadings below to download

	● GDEW029I6FD Specification	● GDEW029I6FD ESP8266 Sample Code
	● UC8151D Driver IC Datasheet	● GDEW029I6FD Arduino Sample Code
	● IC UC8151C to IC UC8151D Instructions	● GDEW029I6FD ESP32 Sample Code
	● Picture Production and Bitmap Convert for GDEW029I6FD	● The latest Catalog of ePaper display
	● GDEW029I6FD STM32 Sample Code	● Why can't I download the files(updated)?

Product Application

Air quality detection label	Wearable device	Shared bike	Logistics label	Smart card
