TIP: The front light is not sold separately due to precise bonding requirements. Please purchase the complete bonded product. For temperature details, refer to the display screen specifications.
Goodisplay Front Light Panel
Move your LED light to the frontThe Goodisplay Front Light Panel is designed to deliver precise lighting for E Ink displays. It reduces power consumption, improves aesthetics, and enables thinner devices. Our ultra-thin optical film integrates seamlessly with the front surface of reflective displays, providing the optimal display module for superior performance. |
 |
|
New Generation of Front-light ePaper |
 |
 |
 |
 |
 |
 |
||
| Resolution: 1600x1200 | Max Grayscale: 16 | Low Power Consumption | PPI: 150.38 | Technology: E Ink Carta 1300 | Full Update: 1s | ||
 |
Our front-lit e-paper display offers:
|
|
|
● Choice between cool white or warm light modes.
● Adjustable brightness by increasing the number of LEDs. ● Flexible circuit design with options for series or parallel configurations. ● We’re introducing the 13.3-inch frontlight module, designed to fit any 13.3-inch E-Ink display. |
Technical Detail |
 |
Product Specifications |
|||||
| PART NUMBER | GDEP133UT3-FL | CONNECTOR | 39 Pin FPC | ||
| TYPE | Dot Matrix | COLOR | Black,White | ||
| SIZE | 13.3 inch | MAX GRAYSCALE | 16 | ||
| RESOLUTION | 1600x1200 | FULL REFRESH(s) | 1 | ||
| OUTLINE SIZE(mm) | 285.80x213.65x0.78 | FRONT-LIT CONNECTOR | 8 pin FPC | ||
| ACTIVE SIZE(mm) | 270.4x202.8(Single screen) | FRONT-LIT NUMBER OF LED LIGHT | 18 | ||
| ACTIVE SIZE(mm) | 0.169x0.169(Single screen) | FRONT-LIT CIRCUIT MODE | Series connection | ||
| OPERATING TEMP. | -15℃~65℃ | FRONT-LIT OPERATING VOLTAGE | 28 | ||
| STORAGE TEMP. | -25℃~70℃ | FRONT-LIT OPERATING CURRENT | 8-10mA | ||
| POWER CONSUMPTION OF THE REFRESH(mW) | 4.5 | STANDBY POWER CONSUMPTION (mW) | 0.003 | ||
Matching Driver Boards |
Files And Download |
|||
| ● GDEP133UT3-FL Specification | ● G133-H11-CAD | ||
| ● GDEP133UT3-FL-CAD | ● GDEP133UT3-FT -CAD | ||
| ● FL133-H01-CAD | ● Why can't I download the files(updated)? | ||
Eco-friendly & Sustainable |
 |
 |
 |
||
Eye-friendly |
|
E-paper technology |
|
No fear of the dark |
| No harmful blue light, so it won't cause any damage to your eyes even with prolonged use. | Eco-friendly and sustainable. Get rid of any paper or printing. | Bright, clear image even in dimly lit spaces. |
Product Application |
 |
 |
 |
 |
Embedded Systems |
Tablets/Portable Devices |
Information Displays |
Wearable Devices or Backpack Displays |
We Also Recommend |
About Us |
||
| Thank you for your interest in our product. We could provide front light, touch screen, and other accessories for you. For more information, please refer to the relevant manual available in our Library or visit our official website at [www.good-display.com].
If you need any further assistance or have any other questions, please feel free to contact us. We sincerely invite you to send your inquiries to our email at [buyepaper@good-display.com].
|
||
